High Speed High Density Signal Conversion PCB Design
Xilinx V6 6U Communication PCB Board Layout Design
Welcome your inquiry
FANY PCB Design Company delivers professional custom PCB board design solutions for high-performance FPGA applications. Our 12-layer 6U CPCI communication board features:
✔ 3.125Gb/s Signal Integrity - Optimized for Xilinx Virtex-6/Spartan-6 FPGAs
✔ Ultra-High Density Layout - 10,255 pins in standard 6U form factor (160×233.35mm)
✔ 20A Power Delivery - Robust power architecture with linear regulators
✔ Full I/O Support - 6U CompactPCI, DDR3, SFP fiber, USB, and RJ45 interfaces
Why Choose Our Printed Circuit Board PCB Design Service?
Allegro/Altium/PADS Experts - 15-day guaranteed design delivery
High-Speed Challenges Solved - 4mil traces, 0.20mm microvias, EMI control
End-to-End Custom PCB Board Design - From concept to production-ready files
Request Design Files or Get a Quote for your Xilinx V6 project today!
